Product Description
The cultural stone production line relates to the technical field of artificial stone production, and discloses an artificial cultural stone mold turning device, comprising a first conveying platform and a second conveying platform arranged in parallel, and a turning frame is arranged between the first conveying platform and the second conveying platform, A clamping mechanism is arranged in the overturning frame, the end of the overturning frame is provided with a holding mechanism corresponding to the clamping mechanism, and the second conveying platform includes a material receiving and conveying mechanism corresponding to the overturning frame and the clamping mechanism.
Features:
1. This equipment is an upgraded version of the above production line; it also has their functions;
2. The feeding method is adjusted from horizontal blanking to bottom-up feeding and feeding, the feeding amount is more stable, and there will be no leakage or uneven material;
3. A weighing system is added, and there is a weighing device under the feeding port, which can weigh concrete within 5-25 kg, making the feeding amount more accurate;
4. The digital display PLC control system is added, which is easy to operate and more intelligent;
5. Configuration: quantitative feeding equipment + 500L mandatory stirring + PLC digital power distribution cabinet.
| Name | Model | Specification | Size (mm) | Power (Kw) | Capacity (m2/day) | Weight (Kg) |
| Artificial stone production line | HTX-P-01 | Hydraulic driving;Auto feeding; vibrating and timing feeding | 7000*1000*1800 | 12.7 | 1000-1200 | 2000 |
| Artificial stone production line | HTX-P-01A | Full Auto,timing feeding and vibration, weighing system; | 12000*1000*2000 | 9.1 | 800-1000 | 2000
|
