Product Description:
A concrete sleeper wall machine, also known as a concrete retaining wall machine or concrete block machine, is a piece of equipment used for manufacturing concrete sleepers or blocks that are used in the construction of walls, particularly retaining walls. These machines are designed to produce large quantities of concrete sleepers efficiently and accurately.
Here's a general overview of how a concrete sleeper wall machine works:
Raw Materials: The machine requires cement, aggregates (such as sand and gravel), water, and sometimes additives depending on the specific requirements of the concrete mix.
Mixing: The raw materials are combined in precise proportions in a mixing chamber or mixer. The mixer ensures that the materials are thoroughly mixed, forming a homogeneous concrete mixture.
Molding: The concrete mixture is then poured into molds or forms that are designed to create the desired shape and size of the concrete sleepers. The molds can be customized to produce different types of sleepers with varying dimensions and surface textures.
Compaction: Once the molds are filled, the machine applies pressure to compact the concrete mixture and remove any air voids. This helps in achieving a strong and durable final product.
Curing: After compaction, the concrete sleepers remain in the molds for a certain period to allow for curing. Curing is the process of maintaining favorable moisture and temperature conditions that promote the proper hardening and strength development of the concrete.
Demolding: Once the curing period is complete, the molds are opened, and the solidified concrete sleepers are removed from the machine. They are then stacked or palletized for further handling and transportation.
It's important to note that the specific design and functionality of concrete sleeper wall machines may vary depending on the manufacturer and the desired output. Some machines may have automated features for improved efficiency, such as automated mold filling, compaction, and demolding processes.
Specification:
| Name | Model | Specification | Size(mm) | Power(Kw) | Capacity(m2/day) | Weight(Kg) |
| Wet Cast Machinery | HTX-P-01 | Hydraulic driving;Auto feeding; vibrating and timing feeding | 7000*1000*1800 | 12.7 | 1000-1500 | 2000 |
| Wet Cast Machinery | HTX-P-02 | Chain drived;Auto feeding,auto vibration | 8000*1100*1600 | 4.05 | 800-1000 | 1500
|
Applications
Wet cast machinery, is suitable for different silicone molds, rubber molds and plastic molds, size range from 200*200mm to 1500*1500mm, available for producing the artificial stone both for paving tile molds, 3D wall molds, wall panel molds, roadside stone molds, retaining wall molds, wall cap molds, etc.
Support and Services
Wet Cast Machinery technical support and services include:
- On-site technical support and maintenance
- Expert assistance with installation and setup
- Remote and telephone troubleshooting and support
- Periodic maintenance and inspection
- Repair and replacement parts
- Technical training and user manuals
- Upgrades and software updates
